HGTR-KTP Pockels Cell
Thatshigh company's improved hydrothermal-grown KTP crystal overcome the common electrochromicm damage of the flux-grown KTP, has high resistivity and high damage threshold. It is suitable for making electro-optic devices with excellent properties.
Typical Applications：
Q-switching
Pulse picking
E-O Modulator
Advantages：
Low Insertion Loss
Low half-wave voltage
No-hygroscopic
Wide optical bandwidth
High laser induced damage threshold
No piezoelectric ringing
Thermally compensated design to operate on large temperate range
Specifications：
|
Transmission at 1064nm |
>98.5% |
|
Aperture |
From 2mm × 2mm to 10mm ×10mm |
|
AR Coatings |
R<0.2%@1064nm |
|
Damage threshold |
>600MW/cm2 at 1064nm, for 10ns pulses |
|
|
X-cut |
Y-cut |
Resistance |
||
|
|
Half- wave voltage(1064nm) |
Extinction Ratio(633nm) |
Half- wave voltage(1064nm) |
Extinction Ratio(633nm) |
|
|
|
V |
dB |
V |
dB |
Ohm.cm |
|
3*3*10mm (pairs) |
1200 |
>20 |
1000 |
>20 |
>1011 |
|
4*4*10mm(pairs) |
1600 |
>20 |
1300 |
>20 |
>1011 |
|
5*5*10mm(pairs) |
2000 |
>20 |
1600 |
>20 |
>1011 |
|
6*6*10mm(pairs) |
2300 |
>20 |
1900 |
>20 |
>1011 |
|
7*7*10mm(pairs) |
2700 |
>20 |
2200 |
>20 |
>1011 |
|
8*8*10mm(pairs) |
3100 |
>20 |
2500 |
>20 |
>1011 |
|
9*9*10mm(pairs) |
3500 |
>20 |
2800 |
>20 |
>1011 |
